I-Bow engabonakaliyo yohlobo lwe-Drop Fiber Optic Cable

I-Invisible Bow-type Drop Fiber Optic Cable yintambo ekhethekileyo yokuhanjiswa kwe-optical eyenzelwe amanethiwekhi okufikelela kumgama omfutshane, ngokukodwa ukulungeleka kwiimeko ezifuna ukufakela okungabonakaliyo. Imveliso yenziwe ngokubeka i-sleeve eqinile engabonakaliyo embindini, ibeka izinto ezimbini zokuqinisa ezihambelanayo kumacala omabini, kwaye ekugqibeleni ikhuphe umaleko we-sheath. Uyilo lwalo lwesaphetha somnqamlezo alugcini nje ukukhulisa uzinzo lwesakhiwo kodwa luqinisekisa nokungabonakali kwekhebula kwiindawo zangaphakathi, ukuphepha impembelelo kwimihlobiso yangaphakathi. I-Invisible Bow-type Drop Fiber Optic Cable yinxalenye ebalulekileyo yomgca wemveliso ye-Orientalfiber, eyilelwe ukuhlangabezana nemfuno ekhulayo yokuhanjiswa kwe-aesthetic kunye ne-optical ebonakalayo kwi-FTTH kunye neeprojekthi ze-cabling zangaphakathi.

Product Ixabiso Core

I-Invisible Bow-type Drop Fiber Optic Cable igxile ekusombululeni iindawo ezibuhlungu zeentambo zokulahla zendabuko ezifana nofakelo oluphazamisayo, ukuhluthwa okunzima kunye nokungahambi kakuhle kunye nokuhombisa kwangaphakathi. Idibanisa ukulula kwesakhiwo, ubunzima obulula kunye nokungabonakali, ukubonelela ngesisombululo esilungeleleneyo sokuhanjiswa komqondiso kunye nokulungelelaniswa kokusingqongileyo. Njengemveliso ephambili ye-Orientalfiber, iye yalungiswa ngokuqhubekayo ngokusekwe kwingxelo yentengiso kunye nophuculo lobugcisa, iqinisekisa ukuba iyakwazi ukuziqhelanisa neendawo ezahlukeneyo zokufakela ngaphakathi ngaphakathi ngelixa igcina ukusebenza kothumelo oluzinzileyo.

Ezona mpawu

Iimpawu zoLwakhiwo

Isakhiwo esilula, ubunzima obulula kunye nokusebenza okuphezulu, okulungele ukuthuthwa kunye nokufakwa kwendawo, ukunciphisa amandla omsebenzi.

Uyilo lwe-Bow-uhlobo olunqamlezayo olunezinto ezimbini zokuqinisa ezihambelanayo kumacala omabini e-sleeve engabonakaliyo ephakathi, ephucula ukusebenza kunye nokuxinwa kwemveliso.

Uyilo lweFlute lwenza kube lula ukukrazula kunye nokudibanisa, ukunciphisa ubunzima bokwakhiwa kwendawo kunye nokuphucula ukusebenza kakuhle kofakelo ngaphandle kwesidingo sezixhobo ezinzima.

Iimpawu zokuSebenza

Ingabonakali kwaye ayinayo impembelelo kumhlobiso wangaphakathi, i-sheath ecacileyo okanye ephantsi-ukubonakala inokudibanisa neendonga, iisilingi kunye nezinye iindawo, ukugcina ingqibelelo yendawo yangaphakathi.

Ukunciphisa ukuhanjiswa okuphantsi, ukwamkela umgangatho ophezulu we-fiber optical core, ukuqinisekisa ukuhanjiswa kwesignali okuzinzileyo kunye nokuhlangabezana neemfuno zokuhanjiswa kwedatha yesantya esiphezulu.

Ukuguquguquka okuhle kokusingqongileyo, ukumelana nobushushu obuphezulu kunye nobushushu obuphantsi, ukufuma kunye nokugqwala, kulungele iindawo ezahlukeneyo zangaphakathi ezifana neendawo zokuhlala, iiofisi kunye nezakhiwo zorhwebo.

Iimpawu zoFakelo

Kulula ukuyifaka, inokubekwa ngokuthe ngqo kwiindonga, iikona okanye ngeepayipi, ngaphandle kwezixhobo zokwakha ezinkulu.

Ukupheliswa kwangaphambili kwifektri kuyafumaneka, enokugcina ixesha lokupheliswa kwendawo kunye nokuqinisekisa ukuhambelana komgangatho woxhulumaniso.

Izinto zokuqinisa ziphucula amandla omatshini wemveliso, ukuphepha umonakalo ngexesha lofakelo kunye nokusetyenziswa.

Uphawu

Isakhiwo esilula, ubunzima obulula kunye nokusebenza okuphezulu

Uyilo lweFlute lwenza kube lula ukuhluba kunye nokudibanisa

Ingabonakaliyo kwaye ayinayo impembelelo kumhlobiso wangaphakathi

Isicelo

Ikheyibhili yangaphakathi

FTTH (IFayibha ukuya eKhaya)

Ipheliswe kwangaphambili kumzi-mveliso

Ulwakhiwo & neMathiriyeli

Ipropati yekhebula

IFayibha Uphawu

Ukusebenza kokusingqongileyo

Onke amaxabiso angasentla angenziwa ngokwezifiso.

IiNgcaciso zobuGcisa

• IiNkcazo ze-Optical

I-Invisible Bow-type Drop Fiber Optic Cable ithatha i-single-mode okanye i-multi-mode optical fiber cores, ithobela i-ITU-T G.652, G.657A2 kunye ne-G.657B3 imigangatho. I-attenuation kwi-1310nm yi-≤0.36dB / km, kwaye i-attenuation kwi-1550nm yi-≤0.22dB / km, iqinisekisa ukuhanjiswa komqondiso welahleko ephantsi. I-aperture yamanani yi-0.200 ± 0.015 (imodi enye) kunye ne-0.275± 0.015 (i-multi-mode), kunye ne-cable cut-off-wavelength yi-≤1260nm, ehambelana nezixhobo eziqhelekileyo zokuhanjiswa kwe-optical kwimarike.

• Iinkcukacha zoomatshini

Imveliso inomsebenzi ogqwesileyo womatshini, kunye namandla okuqina kwexesha elide le-100N kunye namandla okuqina kwexesha elifutshane le-200N. Ukuxhatshazwa kwexesha elide loxinzelelo lwexesha elide ngu-≥1000N / 100mm, kwaye ukunyanzeliswa koxinzelelo lwexesha elifutshane ku-≥2200N / 100mm, enokumelana nokukhupha kunye nokudonsa ngexesha lofakelo kunye nokusetyenziswa. Iradiyasi yokugoba engatshintshiyo yi-15D (D yidayamitha yentambo), kunye neradiyasi eguqukayo yokugoba yi-30D, elungele ukugoba kunye nokubekwa kwiindawo ezimxinwa. Ubunzima obuqhelekileyo bekhebula yi-7.9-9.9kg / km, elula kwaye kulula ukuyiphatha.

• Iinkcukacha zokusingqongileyo

Uluhlu lweqondo lokushisa olusebenzayo lwe-Invisible Bow-type Drop Fiber Optic Cable yi -40 ℃ ukuya ku- +85 ℃, kunye neqondo lokushisa lokugcina -40 ℃ ukuya ku- +85 ℃, elingakwazi ukuziqhelanisa neendawo ezinzima zenguqu zangaphakathi nangaphandle. Impahla ye-sheath ithatha i-LSZH (i-Low Smoke Zero Halogen) impahla, engeyiyo ityhefu, i-flame-retardant kunye nendalo engqongileyo, ihlangabezana neemfuno zokhuseleko lweendawo zoluntu kunye neendawo zokuhlala. Ikwahambelana neRoHS, CE kunye neminye imigangatho yokusingqongileyo yamazwe ngamazwe.

• Iinkcukacha ngokwasemzimbeni

Ubungakanani bangaphandle bekhebula ngu-2.0 × 3.0mm (± 0.2mm), kunye nesakhiwo esincinci, esilungele ukubeka kwiipayipi ezincinci kunye nezikhewu. Ubunzima be-sheath yi-0.5-0.8mm, iqinisekisa ukukhuselwa kwe-fiber optical yangaphakathi kunye nezinto zokuqinisa. Izinto zokuqinisa zingakhethwa njengentsimbi okanye i-non-metal (FRP) ngokweemfuno zabathengi, ukuhlangabezana neemeko ezahlukeneyo zofakelo kunye neemfuno zokhuseleko.

Usetyenziso

Imiba yeSicelo esiPhambili

I-Invisible Bow-type Drop Fiber Optic Cable isetyenziswa ngokubanzi kwiimeko ezahlukeneyo zokuhanjiswa kwe-optical optical umgama omfutshane, ugxininise kwiindawo zangaphakathi kunye ne-FTTH. Ukungabonakali kwayo kunye nokufakwa lula kwenza imveliso ekhethiweyo kwiiprojekthi ezininzi. Imveliso isetyenziswa ngokubanzi kumashishini onxibelelwano lwasekhaya nangaphandle, unomathotholo kunye nomabonwakude kwiinkqubo zonxibelelwano kunye nolwazi losasazo, iinkqubo zothumelo lwedatha yenethiwekhi yendawo kunye noqhagamshelo lwangaphambili lweshishini kumandla ombane, ukuhamba ngololiwe, iindlela ezinkulu kunye namanye amashishini.

Iimeko ezithile zeSicelo

FTTH (IFayibha ukuya eKhaya)

Njengoko i-core transmission medium yeeprojekthi ze-FTTH, i-Invisible Bow-type Drop Fiber Optic Cable idibanisa i-community optical distribution box kwikhaya lomsebenzisi, iqonda ukufikelela kwi-broadband ye-high-speed. Uyilo lwayo olungabonakaliyo lugwema umonakalo kumhlobiso wendlu, kwaye ukukrazula okulula kunye ne-splicing feature kunciphisa ubunzima bokufakelwa kwekhaya. Ifanelekile kwiindawo ezintsha zokuhlala, ukulungiswa koluntu oludala kunye nezinye iiprojekthi ze-FTTH, ukubonelela ngenkxaso ezinzileyo yevidiyo ye-4K / 8K, amava e-VR kunye nezicelo zekhaya ezihlakaniphile.

I-Indoor Cabling

Kwizakhiwo zeofisi, izakhiwo zorhwebo, izibhedlele, izikolo kunye nezinye iindawo zangaphakathi, i-Invisible Bow-type Drop Fiber Optic Cable isetyenziselwa ukudibanisa i-horizontal cabling kunye nezixhobo zokusebenza. Inokubekwa ecaleni kweendonga, iisilingi okanye ngemibhobho efihliweyo, igcina ukucoceka kunye nobuhle bemeko yangaphakathi. Imveliso ifanelekile ukuhanjiswa kwedatha yenethiwekhi yendawo yendawo, ukuqonda uxhulumaniso olukhawulezayo phakathi kwemigangatho kunye nezixhobo, kunye nokuxhasa iinkomfa zevidiyo, ukuvumelanisa idatha enkulu kunye namanye amashishini aphezulu.

Ii-Factory Applications ezipheliswe kwangaphambili

I-Invisible Bow-type Drop Fiber Optic Cable inokupheliswa kwangaphambili kwifektri ngokweemfuno zabathengi, ukunciphisa ixesha lokwakhiwa kwendawo kunye nokuphucula inkqubela yeprojekthi. Isetyenziswa ngokubanzi kwiiprojekthi ezinkulu ze-FTTH, amaziko edatha kunye nezinye iimeko ezifuna ukufakela ngokufanelekileyo, ukuqinisekisa ukuhambelana nokuthembeka komgangatho woxhulumaniso.

Iimeko ezikhethekileyo

Kwezinye iimeko ezineemfuno eziphezulu ze-aesthetics yendalo, njengeendawo zokuhlala eziphezulu, iigalari zobugcisa kunye neehotele ezinqabileyo, i-Invisible Bow-type Drop Fiber Optic Cable inokudibanisa nokusingqongileyo, ukuphepha impembelelo yeentambo zendabuko kwisitayela sonke. Kwangaxeshanye, inguqulelo yayo engeyo-metal yokuqinisa ingasetyenziswa kumaziko ombane, amasimi e-oyile kunye nezinye iimeko ezinovakalelo kukuphazamiseka kwe-electromagnetic, ukuqinisekisa ukuhanjiswa komqondiso ozinzile.
