I-Mobile Fiber Optic Cable MOC

I-Mobile Fiber Optic Cable MOC evela kwi-Orientalfiber China Factory yenzelwe ukwenza lula i-branching kunye ne-fiber extraction ngexesha lofakelo. Ukusebenzisa i-micro-tubes njengeeyunithi ze-optical, le ntambo isekela ulawulo lwefiber ehleliweyo kunye nokufikelela ngokukhawuleza. NjengoMboneleli kunye noMvelisi othembekileyo, sigxininisa kuyilo lwesakhiwo esizinzile kunye nomgangatho wemveliso ongaguqukiyo ukuhlangabezana neemfuno ezahlukeneyo zecabling zangaphakathi.

Uyilo lwesakhiwo

Ulwakhiwo olungundoqo

• Iiyunithi ze-Micro-tube ezenziwe nge-fiber optical kunye nezixhobo zokukhusela
• I-Special cross-section LSZH sheath yangaphandle
• Amalungu amabini ahambelanayo anamandla e-FRP okomeleza
• Ukumakishwa komkhomba-ndlela kwisingxobo ukuze uvuleke lula

Injongo yoyilo

• Ukuphucula ulawulo lwefayibha ngokufanelekileyo
• Ukuxhasa ukufikelela ngokukhawuleza kunye ne-branching kwinethiwekhi zangaphakathi
• Gcina uzinzo lwesakhiwo ngexesha lofakelo kunye nokusetyenziswa

Ezona mpawu

Ukufakela okuguquguqukayo

• Ubungakanani obuncinci kunye nobunzima obulula bokuphatha lula
• Ukuhamba ngokufanelekileyo kwi-shafts ezithe nkqo kunye neendawo ezivaliweyo
• Ixhasa ukusika ngokukhawuleza kunye nokutsalwa kwefayibha

Ulawulo lweFayibha ngokuLungileyo

• Uyilo lwe-Micro-tube lwenza lula ukuchongwa kwefiber
• I-branching elula ngaphandle kokonakalisa imicu ekufutshane
• Ilungele ukusasazwa kwenethiwekhi ngokweqonga

Ukusebenza koKhuseleko

• Umsi ophantsi we-halogen-free sheath unciphisa umngcipheko womlilo
• Izixhobo ezithintela amadangatya ezifanelekileyo kwizakhiwo ezingqongileyo

Ukuthembeka koomatshini

• Ukuqiniswa kwe-FRP kwandisa amandla okuqina
• Ukusebenza okuzinzileyo phantsi kokugoba kunye nokunyanzeliswa
• Ukuziphatha okuhambelanayo kuwo wonke umahluko wobushushu

IiNgcaciso zobuGcisa

I-Mobile Fiber Optic Cable MOC ixhasa iinketho zoqwalaselo ezibhetyebhetye:

• Uhlobo lweFayibha: G652D / G657A ngokuzikhethela
• Ubalo lweFayibha: inokwenzeka (ngokusekwe kuyilo lweprojekthi)
• Ulwakhiwo: uyilo lweyunithi encinci yetyhubhu
• Ilungu lamandla: i-FRP edibeneyo emibini
• Isingxobo sangaphandle: I-LSZH i-flame retardant material
• Idayamitha yekhebhula: uyilo oludityanisiweyo lwendlela yangaphakathi
• Ubushushu bokusebenza: ngokwesiqhelo -20°C ukuya +60°C

Ukuhanjiswa kwefayibha yangaphakathi ecwangcisiweyo, i-Mobile Fiber Optic Cable MOC ibonelela ngesisombululo esisebenzayo kunye nofakelo oluguquguqukayo, ulawulo lwefiber olucwangcisiweyo, kunye nokusebenza komatshini okungaguqukiyo.

Isicelo semveliso

FTTH iingcingo zangaphakathi ezithe nkqo

Ukwakha i-trunk wiring optical cable

Iimpawu zemveliso

Uyilo oluhle lolwakhiwo, kulula ukwenza isebe kunye nokukhupha

Ubungakanani obuncinci, ubunzima obulula, kulula ukuyifaka

Umsi ophantsi we-halogen-free sheath uqinisekisa ukulibaziseka okuhle komlilo

Ulawulo lwenkqubo oluchanekileyo luqinisekisa ukusebenza koomatshini kunye nobushushu

Ngokukodwa kufanelekile ukusika, ukutsalwa, ukuvulwa kwesibhakabhaka

IiParameters zobuGcisa

Uhlobo lweCable	I-Cable Diameter	Ubunzima beCable	Amandla okuqina ixesha elide/elifutshane	Ukuxhathisa Ukunyathela Ixesha elide / elifutshane	Ukugoba iRadius Dynamic/Static	Ubushushu bokugcina
	(mm)	(kg/km)	(N)	(N)	(mm)	(℃)
I-GJPFWQH-24 (4cx6s)	6.5±0.2	40	200/500	200/1000	20D/10D	-20°C ~ +60
GJPFWQH-48 (4cx12s)	8.5±0.2	60	200/500	200/1000	20D/10D	-20°C ~ +60
I-GJPFWQH-96 (8cx12s)	10.5±0.2	90	200/500	200/1000	20D/10D	-20°C ~ +60
GJPFWQH-144	10.5±0.2	90	300/500	200/1000	20D/10D	-20°C ~ +60
GJPFWQH-144	13.5±0.2	145	300/500	200/1000	20D/10D	-20°C ~ +60

Qaphela: Ubushushu bokuthutha/ugcino: -20°C ~ +60°C

Ubude obuqhelekileyo: 2000m; ezinye ubude nazo ziyafumaneka.

Uhlobo lweFayibha: G652D, G657A1, G657A2, 50/125, 62.5/125, OM3, OM4, OM5

Usetyenziso

· Iinkqubo zocingo ezithe nkqo ze-FTTH zangaphakathi

· Ukwakhiwa kwe-trunk optical cable deployment

· Amagumbi onxibelelwano kunye neeshafti zokunyuka

· Ukuhanjiswa kwedatha kwiinkqubo zeLAN

· Uphuculo lothungelwano lwangaphakathi kunye neeprojekthi zokwandisa

I-Mobile Fiber Optic Cable MOC ifaneleka ngokukodwa kwiiprojekthi ezifuna i-branching rhoqo kunye nolwabiwo lwefayibha ebhetyebhetye, njengezakhiwo ezinemigangatho emininzi kunye nofakelo oluhleliweyo.

Iingenelo Ekusetyenzisweni Okuluncedo

· Xa kuthelekiswa neentambo zemveli zangaphakathi, ivumela ukutsalwa lula kwefayibha

· Ukuphucula ukufaneleka kofakelo kwiindawo ezinoxinano oluphezulu

· Yehlisa umngcipheko wokonakala kwefayibha ngexesha lomsebenzi we-branching

· Ixhasa ukwandiswa kwenethiwekhi kwixesha elizayo ngaphandle kokubuyisela intambo ephambili

Iimeko zeSicelo kunye ne-Industry UseIn izakhiwo zorhwebo, i-Mobile Fiber Optic Cable MOC inceda ukwenza lula i-cabling ethe nkqo kunye nokunciphisa ixesha lofakelo. Kwiiprojekthi zokuhlala ze-FTTH, ixhasa ukuhanjiswa kwefayibha ezicwangcisiweyo kwimigangatho yonke. Xa kuthelekiswa neentambo eziqhelekileyo ze-tight-buffer, olu luyilo lubonelela ngokuguquguquka okungcono kugcino kunye nophuculo.

FAQ

I-Q1: Yiyiphi inzuzo ephambili ye-Mobile Fiber Optic Cable MOC?

Ivumela i-fiber extraction elula kunye ne-branching ngaphandle kokuchaphazela yonke i-cable structure.

I-Q2: Ngaba i-Mobile Fiber Optic Cable MOC ifanelekile kwizakhiwo eziphakamileyo?

Ewe, yenzelwe iingcingo ezithe nkqo kunye nezicelo ze-trunk yokwakha.

I-Q3: Ngaba uqwalaselo lwefiber lunokwenziwa ngokwezifiso?

Ewe, inani lefayibha kunye nohlobo lunokulungelelaniswa ngokweemfuno zeprojekthi.

I-Q4: Ngaba intambo ikhuselekile ukuba isetyenziswe ngaphakathi?

Ewe, i-sheath ye-LSZH iyanciphisa umsi kunye nokukhutshwa okuyingozi, okwenza ukuba ifaneleke kwiindawo zangaphakathi.
