Iimowudi ezininzi zeFayibha ye-Optical OM2+/OM3

I-Orientalfiber Multi-mode Optical Fiber OM2+/OM3 yenzelwe ukuhanjiswa kwesantya esifutshane ukuya kumgama ophakathi kwiindawo zothungelwano zanamhlanje. Njengomvelisi waseTshayina kunye nomthengisi, i-Orientalfiber inikezela nge-Multi-mode Optical Fiber OM2 +/OM3 kunye nokusebenza kwe-laser-optimized kwi-850nm, ixhasa izicelo ze-Ethernet ukuya kwi-100Gbps, ngokukodwa isetyenziswe ngokubanzi kwi-10 ye-Gigabit Ethernet yokuthunyelwa kuwo wonke amaziko edatha kunye neenethiwekhi zamashishini.

Thumela uMbuzo

Ingcaciso yeMveliso

I-Multi-Mode Optical Fiber OM2+/OM3 ine-50μm core diameter kunye ne-aqua blue sheath yangaphandle ukuze uchongeke lula. Ilungiselelwe ukusetyenziswa kunye ne-850nm yemithombo ye-laser ye-VCSEL, iyenza ibe yinto eqhelekileyo kwiinkqubo zonxibelelwano lwedatha yesantya esiphezulu. Xa kuthelekiswa nemicu yemveli ye-multimode, le mveliso iphucula i-bandwidth kwaye inciphisa ukuphazamiseka kwesignali, inceda ukugcina ukuhanjiswa okuzinzile.

Imigangatho & ukuthotyelwa

I-Orientalfiber Multi-Mode Optical Fiber OM2+/OM3 idibana okanye igqithe le migangatho ilandelayo yamazwe ngamazwe:

ISO/IEC 11801-1 OM3
IEC 60793-2-10 A1-OM3
TIA-492AAAF A1-OM3

Iimpawu eziphambili kwiNdlela yokuThengwa kweeMpahla

Ilungiselelwe 850nm Imithombo yokukhanya yeVCSEL
I-Multi-mode Optical Fiber OM2 +/OM3 yenzelwe ngokukodwa ukuhanjiswa kwe-850nm VCSEL, ukuqinisekisa ukudityaniswa kwesignali esebenzayo kunye nokudluliselwa kwedatha yesantya esiphezulu kwiinkqubo ze-Ethernet.

Ixhasa i-High-Speed Ethernet ukuya kuthi ga kwi-100Gbps
Le fiber isekela imigangatho eyahlukeneyo ye-Ethernet engaphantsi kwe-100Gbps, kunye ne-10G Ethernet enye yezona zicelo eziqhelekileyo, okwenza ukuba zilungele zombini ukuthunyelwa kwangoku kunye nokuphuculwa kwexesha elisondeleyo.

UkuBuya Ukuhambelana koManyano oluguquguqukayo
Iyahambelana ne-OM2 +, i-OM3, kunye ne-OM4 i-multimode fibers, evumela ukuhlanganiswa okungenamthungo kwiziseko zonxibelelwano ezikhoyo ngaphandle kohlengahlengiso olukhulu.

Ukuthotyelwa okuPhantsi kunye nobubanzi obuphezulu
Ukulahleka kweempawu ezisezantsi kunye nomthamo ophezulu we-bandwidth kunceda ukugcina ukuhanjiswa kwedatha okuhambelanayo, okubaluleke kakhulu kwiindawo ezinzulu zedatha njengamaziko edatha kunye neenkqubo zokugcina.

I-DMD eyehlisiwe yoZinzo lweSiqondiso
Ukulibaziseka kwemodi yokwahlukana okuphantsi (i-DMD) inceda ukunciphisa ukuphazamiseka komqondiso, ukuphucula umgangatho wothumelo jikelele kwizicelo ezikhawulezayo.

Ukuphuculwa Ukugoba Ukumelana
Ukuchasana okuphuculweyo kwi-micro-bending kunciphisa umngcipheko wofakelo kunye nokugcina ukusebenza nakwiindawo eziyinkimbinkimbi zomzila.

Iimeko zosetyenziso oluqhelekileyo

Ukusuka kubunjineli kunye nombono wokuthenga, i-Multi-mode Optical Fiber OM2 +/OM3 isetyenziswa ngokubanzi kwi:

Amaziko edatha kunye namagumbi omncedisi
Iinethiwekhi zokugcina idatha
Amaziko ekhompuyutha asebenza kakuhle (HPC).
Uthungelwano lwengingqi (LAN)
Iinkqubo ze-Ethernet zeShishini

Kutheni ukhetha iOrientalfiber

I-Orientalfiber ixhaswa yi-Jiangsu Xuben Photoelectric Technology Co., Ltd, inkampani yeqela enezixhobo ezine ezikhethekileyo zokuvelisa ezigquma iintambo zangaphakathi, iintambo zangaphandle, amacandelo e-ODN, kunye nezixhobo zenethiwekhi zamehlo.

Ngommandla opheleleyo wemveliso we-15,000 square metres kunye nexabiso lemveliso yonyaka elifikelela kwi-20 yezigidi ze-USD, inkampani ixhasa ukubonelela ngobuninzi kunye nomgangatho wemveliso ongaguqukiyo. Iimveliso zayo zisetyenziswa ngokubanzi kunxibelelwano ngemfonomfono, usasazo, iziseko zombane, uthutho lukaloliwe, kunye neenkqubo zonxibelelwano lwamashishini.

Ukuqinisekiswa nge-ISO9001 kunye ne-ISO45001 iinkqubo, umenzi uqinisekisa imveliso ezinzileyo, ukuqinisekiswa komgangatho, kunye nokuthembeka kwentsebenziswano yexesha elide kubathengi behlabathi.

IiNgcaciso zeXabiso lokuThenga

Isisombululo esingabizi kakhulu kumgama omfutshane kunye nophakathi wothungelwano olunesantya esiphezulu
Ukudityaniswa lula kunye nesiseko sefiber ekhoyo yemultimode
Ukusebenza okuzinzileyo kwiindawo ezinzulu zedatha
Ilungele ukuphuculwa kwenethiwekhi enokunyuka

FAQ

Q1: Uthini umahluko phakathi kwe-OM2 + kunye ne-OM3 fiber?
I-OM3 inikezela nge-bandwidth ephezulu kwaye ilungiselelwe ukuhanjiswa kwe-laser, ngelixa i-OM2 + ibonelela ngokusebenza okuphuculweyo xa kuthelekiswa ne-OM2 eqhelekileyo. I-Multi-mode ye-Optical Fiber OM2 +/OM3 idibanisa ukuhambelana kunye nokukwazi ukuhanjiswa okuphuculweyo.

I-Q2: Ngaba le fiber ifanelekile kwiinethiwekhi ze-10G?
Ewe, i-Multi-mode Optical Fiber OM2 +/OM3 isetyenziswa ngokubanzi kwi-10 Gigabit Ethernet kwaye ixhasa isantya esiphezulu ngokuxhomekeke kumgama kunye nokucwangciswa kwenkqubo.

I-Q3: Ngaba inokusetyenziswa kwiinkqubo ezikhoyo ze-cabling?
Ewe, ibuyela ngasemva iyahambelana ne-OM2 +/OM3/OM4 fibers, iyenza ilungele ukuphuculwa okanye imo yenethiwekhi edibeneyo.

I-Q4: Iphi le mveliso isetyenziswa ngokuqhelekileyo?
Isetyenziswa ngokuqhelekileyo kumaziko edatha, iiLAN zamashishini, kunye neendawo eziphezulu zokusebenza zekhompyutha apho ukuhanjiswa kwedatha okuthembekileyo kuyadingeka.

Imigangatho

I-OM3 ye-multimode ye-bend-insensitive fiber idibana okanye idlula i-ISO / IEC 11801-1 OM3 inkcazo, i-IEC 60793-2-10 i-A1-OM3 inkcazo, kunye ne-TIA-492AAAF A1-OM3.

Usetyenziso

Amaziko edatha

Iinethiwekhi zokugcina idatha

Amaziko ekhompyutha asebenza kakuhle a

Uthungelwano lwengingqi (LAN)

I-Ethernet

Iimpawu

I-1 Elungiselelwe i-850nm VCSELs

I-2 Iyahambelana ne-OM2 + / OM3 / OM4 i-multimode fibers yangoku

I-3 egqwesileyo yejometri efanayo

4 Ukujongelwa phantsi

5 I-bandwidth ephezulu

6 Ulibaziseko lwemowudi ephantsi (DMD)

7 Ukuxhathisa okuphezulu kwi-micro-bending

8 Ukusebenza okuzinzileyo kuluhlu olubanzi lweemeko zokusingqongileyo

Iinkcukacha

Iimpawu	Iimeko	Icacisiwe ixabiso	Iiyunithi
Ijometri Iimpawu
Undoqo Ububanzi	--	50±2.5	[μm]
Undoqo Non-Setyhula	--	≤5.0	[%]
Ukugquma Ububanzi	--	125.0±1.0	[μm]
Ukugquma Non-Setyhula	--	≤0.6	[%]
Ukwaleka Ububanzi	--	245±7	[μm]
Ukwaleka/Ukwalekwa Imposiso yoxinaniso	--	≤10.0	[μm]
Ukwaleka Non-Setyhula	--	≤6.0	[%]
Undoqo/Ukwambathisa Imposiso yoxinaniso	--	≤1.0	[μm]
Ukuhanjiswa Ubude	--	phezulu ukuya ku8.8	[km/reel]
I-Optical Iimpawu
Ukuthotywa	850nm	≤2.4	[dB/km]
Ukuthotywa	1300nm	≤0.6	[dB/km]
--	--	IMaxBand® I-OM2 +/OM3/OM4 Gobela Ukungaziva
Igcwaliswe ngaphezulu I-Modal Bandwidth	850nm	≥700/≥1500/≥3500	[MHz·km]
Igcwaliswe ngaphezulu I-Modal Bandwidth	1300nm	≥500/≥500/≥500	[MHz·km]
Isebenza I-Modal Bandwidth	850nm	≥950/≥2000/≥4700	[MHz·km]
Isicelo umgama inkxaso kwi	--	--	--
40GBASE-SR4 / 100GBASE-SR101	850nm	-/140/170	[m]
I-10GBASE-SR	850nm	150/300/550	[m]
1000BASE-SR	850nm	750/1000/1100	[m]
I-DMD Iinkcukacha	Ukuthobela kunye kunye nokungqongqo ngakumbi kuneemfuno ze-IEC60793-2-10		--
Ngamanani Umngxuma wokuvula	--	0.200±0.015	--
Iqela Refractive Index	850nm	1.482	--
Iqela Refractive Index	1300nm	1.477	--
Zero Dispersion Wavelength(λ0)	--	1295-1340	[nm]
I-Zero Dispersion Slope(S0)	1295nm≤λ0≤1310nm	≤0.105	[ps/(nm2·km)]
I-Zero Dispersion Slope(S0)	1310nm≤λ0≤1340nm	≤0.000375(1590-λ0)	[ps/(nm2·km)]
IMacrobending Ilahleko2	--	--	--
2 Ijika @ 15 mm Radius	850nm	≤0.1	[dB]
2 Ijika @ 15 mm Radius	1300nm	≤0.3	[dB]
2 Ijika @ 7.5 mm Radius	850nm	≤0.2	[dB]
2 Ijika @ 7.5 mm Radius	1300nm	≤0.5	[dB]
Backscatter Iimpawu	1300nm
Inyathelo (iNdlela yoMlinganiselo weBidirectional)	--	≤0.10	[dB]
Izitenxo Ngaphezulu koBude beFayibha kunye nokuNgaqhubeki	--	≤0.10	[dB]
Ukuthotywa Ukufana	--	≤0.08	[dB/km]
Okusingqongileyo Iimpawu	850nm & 1300nm
Ubushushu Ukukhwela ibhayisekile	-60℃ukuya ku-85℃	≤0.10	[dB/km]
Ubushushu-Ukufuma Ukukhwela ibhayisekile	-10℃ ukuya ku-85℃,4% ukuya kuma-98% RH	≤0.10	[dB/km]
Amanzi Ukuntywiliselwa	23℃, iintsuku ezingama-30	≤0.10	[dB/km]
Yomile Ubushushu	85℃, iintsuku ezingama-30	≤0.10	[dB/km]
Kufumile Ubushushu	85 ℃, 85% RH, iintsuku ezingama-30	≤0.10	[dB/km]
Oomatshini Inkcazo
Ubungqina Uvavanyo	--	≥9.0	[N]
	--	≥1.0	[%]
	--	≥100	[kpsi]
Ukwaleka Strip Force	eqhelekileyo amandla aphakathi	1.5	[N]
Ukwaleka Strip Force	incopho amandla	≥1.3, ≤8.9	[N]
Uxinzelelo lweDynamic Stress Corrosion Susceptibility Parameter (nd, eqhelekileyo)	--	20	--

Multi-mode Optical Fiber OM2+/OM3
