I-Bow-type Duct Fiber Optic Drop Cable

Uhlobo lwe-Bow-Type ye-Fiber Optic Drop Cable yenzelwe unxibelelwano oluthembekileyo lwe-optical, inika amandla abalaseleyo okuqina, ukuthintela amanzi, kunye nokufakwa lula. Njengomvelisi othembekileyo kunye nomthengisi e-China, i-Orientalfiber ihambisa le Cable ye-Fiber Optic Drop Cable ngokuthe ngqo kumzi-mveliso wabaqhubi be-telecom, uthungelwano lwedatha, kunye noqhagamshelo lwangaphambili lwemizi-mveliso. Iqinisekisa ukusebenza, uzinzo, kunye neendleko ezifanelekileyo kwiiprojekthi ezahlukeneyo.

Thumela uMbuzo

Ingcaciso yeMveliso

Umgangatho wethu ophakamileyo we-Bow-type Duct Fiber Optic Drop Cable zonke zenziwe eTshayina. I-Orientalfiber yingcali yohlobo lwe-Bow-Type Fiber Optic Drop Cable umenzi kunye nomthengisi e-China. Unokuzithenga kumzi-mveliso wethu. Ukuze ufumane inkcazelo engakumbi, qhagamshelana nathi ngoku.

I-Bow-type Duct Fiber Optic Drop Cable yintambo ekhethekileyo ye-optical yofakelo lwe-duct, eyenzelwe ukuxhasa uxhulumaniso lwe-mile-mile yokugqibela, kuquka i-Fiber To The Home (FTTH) kunye ne-industrial-end-end connections. Ukwakhiwa kwayo okuguquguqukayo kunye noyilo olulomileyo lokuthintela amanzi kuvumela ukuqhawula ngokukhawuleza kunye nokudibanisa, ukunciphisa ixesha lokufakela kunye nomgudu.

Iingenelo ezingundoqo

Isakhiwo esomileyo esinamanzi-ukuthintela ukusebenza okuthembekileyo
Uxinzelelo oluphezulu kunye nokumelana nokutyumza kweendawo ezifunayo
Uyilo olugudisiweyo luqinisekisa ukuhluba ngokukhawuleza kunye nokuchanekileyo kunye nokudibanisa
Ikhaphukhaphu kodwa ihlala ixesha elide, inciphisa ukuphatha kunye nomzamo wokulondoloza
Unikezelo oluthe ngqo oluvela kwi-Orientalfiber, umenzi othembekileyo waseTshayina kunye nomthengisi

Isicelos

Ikhoyibhili yombhobho wangaphakathi nangaphandle
IFayibha ukuya eKhaya (FTTH) iinethiwekhi
Izisombululo zasefektri ezipheliswe kwangaphambili
Uqhagamshelo lwangaphambili lweshishini kumandla, ukuhamba koololiwe, kunye noohola bendlela

Ulwakhiwo & neMathiriyeli

Hayi.	Into	Izinto eziphathekayo
1	Isingxobo sangaphakathi	PVC, LSZH
2	Ukomelela ilungu	ucingo lwentsimbi, FRP, KFRP
3	Ifayibha	G.652D (B1.3), G.657A1 (B6a1), G.657A2 (B6a2) …
4	Ilungu elixhasayo lamandla	Ucingo lwentsimbi, FRP
5	Izinto ezithintela amanzi	Iteyiphu yokuthintela amanzi
6	Isingxobo sangaphandle	LSZH, PE
7	Umbala	Mnyama

Bow-type Duct Fiber Optic Drop Cable

Ipropati yekhebula

Uhlobo lwentambo	Ubungakanani		Tensile strength		Ukuxhathisa ukutyumza		Iradiyasi yokugoba
	Iyunithi	Intambo	Ixesha elide	Ixesha elifutshane	Ixesha elide	Ixesha elifutshane	I-Static	Unamandla
	(mm)		(N)		(N/100mm)		—
GJYXFH03 - 1/2/4	2.0×3.0	6.2	300	600	1000	2200	10·D	20·D
GJYXH03 - 1/2/4	2.0×3.0	6.2	300	600	1000	2200	10·D	20·D

Amanqaku: D = Idayamitha yekhebula.

IFayibha Uphawu

Uhlobo lweFayibha	Uthintelo ( Ubukhulu)		Ilahleko enkulu yokugoba ( Ubukhulu)
	1310nm	1550nm	Φ30mm 10 izangqa(ukujika)	Φ20mm 1 izangqa(jiko)	Φ15mm 1 izangqa(jiko)	Φ32mm 1 izangqa(jiko)	Φ60mm 100 izangqa (ukujika)
	(dB/km)		(dB)
G.652 D	0.40	0.30	N / A	N / A	N / A	0.05 @1550nm	0.05 @ 1625nm
G.657 A1	0.40	0.30	0.25 @1550nm 1.00 @1625nm	0.75 @1550nm 1.50 @1625nm	N / A	N / A	N / A
G.657 A2	0.40	0.30	0.03 @ 1550nm 0.10 @1625nm	0.1 @1550nm 0.2 @1625nm	0.5 @1550nm 1.0 @1625nm	N / A	N / A

Ukusebenza kokusingqongileyo

Ezothutho & noGcino	Ukuhlohla	Ukusebenza	Amagqabantshintshi
-40℃ — +60℃	-30℃ — +50℃	-40℃ — +60℃	RoHS

Onke amaxabiso angasentla angenziwa ngokwezifiso.

Iithegi ezishushu: I-Bow-type Duct Fiber Optic Drop Cable
