Ukuzixhasa kwe-Bow-type Fiber Optic Drop Cable

I-Self-supporting Bow-type ye-Fiber Optic Drop Cable yenzelwe ukufakelwa kwe-fiber optic ephezulu kunye nokuqina okuphezulu kunye nokulula ukuyisebenzisa. Eyilwe kunye neyunithi yokunxibelelana kwe-optical kwi-core yayo, iqiniswe yi-FRP okanye i-metal components kunye nentsimbi yentsimbi yokuqiniswa kwangaphandle, le ntambo iqinisekisa ukusebenza okuthembekileyo kwedatha kunye neenethiwekhi zonxibelelwano. Umsi omnyama okanye onemibala ephantsi, i-halogen-free (LSZH) sheath inika ukhuseleko lokusingqongileyo, okwenza ukuba ifaneleke kwiindidi ezahlukeneyo zokuthunyelwa. Le ntambo ilungele iipali eziluncedo, iikhabhathi zesitalato, kunye nolunye uthungelwano lwe-aerial fiber optic.

Thumela uMbuzo

Ingcaciso yeMveliso

I-Self-supporting Bow-type ye-Fiber Optic Drop Cable ibonisa iyunithi ye-fiber optical central ekhuselwe ngama-FRP amabini afanayo okanye amalungu e-metal reinforcement. Ucingo olunye lwentsimbi longezwa ngaphandle ukomeleza amandla okuqina, okuvumela intambo ukuba ikwazi ukuzixhasa kufakelo lwasemoyeni. Idizayini yodidi lwesaphetha inoveli inciphisa ubunzima ngelixa igcina amandla omatshini. Ulwakhiwo lwayo olulula luvumela ukuhluthwa lula, ukuhlanganisa, kunye nokugcinwa.

Iimpawu eziphambili

Amalungu amabini ahambelanayo e-FRP okanye amandla entsimbi anika ukuxhathisa okugqwesileyo.
Ukuqiniswa kocingo lwentsimbi enye yongeza amandla okuqina ukuze asetyenziswe ngaphezulu.
Isakhiwo esilula, esisebenzayo sofakelo kunye nokugcinwa lula.
Idizayini yodidi lwesaphetha entsha yenza lula ukuhluba kunye neenkqubo zokuhlanganisa.
Isingxobo se-LSZH siqinisekisa ukubuyiswa komlilo, umsi ophantsi, kunye nokhuseleko lokusingqongileyo.

Umzobo wesakhiwo

Ibhatyi yeLSZH
Ilungu le-FRP lamandla
Iyunithi yeFayibha yokubona
Ukuqiniswa kocingo lwentsimbi

Usetyenziso

Imigca yokuhla yefiber optic engaphezulu kuthungelwano lonxibelelwano
Iikhabhathi zasezitalatweni kunye nothungelwano lokufikelela kwimayile yokugqibela
Ukusasazwa kwebroadband ezidolophini nasemaphandleni
Ufakelo lwefayibha ngaphezulu kweshishini

Iingenelo ezingundoqo

IUkuzixhasa kwe-Bow-type Fiber Optic Drop Cableinikeza:

Ukusebenza okuthembekileyo komatshini kwiindawo eziphezulu
Ukukhuselwa ngokuchasene nokutyumza, ukutsala, kunye nemiba yokusingqongileyo
Ikhaphukhaphu kwaye kulula ukuyifaka uyilo
Ijacket ye-LSZH ehlala ixesha elide yokusetyenziswa kwangaphandle ixesha elide
Uyilo olungqiniweyo olufanelekileyo kubaqhubi be-telecom kunye neenethiwekhi zedatha

Self-supporting Bow-type Fiber Optic Drop Cable

Iiparamitha zobuGcisa

Umzekelo weCable	Ukubalwa kweFayibha	Ubungakanani beCable (mm)	Ubunzima beCable (Ref) (kg/km)	Tensile strength Ixesha elide/elifutshane (N)	Ukuxhathisa ukutyumza Ixesha elide/elifutshane (N/100mm)	Ukugoba iRadiyosi Dynamic/Static (mm)
GJYXFCH-1Xn	1	(2.0±0.1)*(5.0±0.1)	20	300/600	1000/2200	15/30
GJYXFCH-2Xn	2	(2.0±0.1)*(5.0±0.1)	20	300/600	1000/2200	15/30
GJYXFCJH-1Xn	1	(2.0±0.1)*(5.6±0.1)	21	300/600	1000/2200	15/30
GJYXFDH-4Xn	4(Iribhoni)	(2.0±0.2)*(6.0±0.2)	22	300/600	1000/2200	15/30

UGcino/Ubushushu bokusebenza: -20℃~+60℃

Iimpawu ze-Optical

Uhlobo lweFayibha	Ukuthotywa				OFL	Uluhlu lwendlela esebenzayo	I-10 Gbit/s Ethernet Ubude bekhonkco	Ubuncinci Bend Radius
Imeko	1310/1550nm		850/1300nm		850/1300nm	850nm	850nm	/
Imeko	Ixabiso eliqhelekileyo	Ixabiso eliphezulu	Ixabiso eliqhelekileyo	Ixabiso eliphezulu	850/1300nm	850nm	850nm	/
Iyunithi	dB/km	dB/km	dB/km	dB/km	MHZ.km	MHZ.km	m	mm
I-G657A1	0.36/0.22	0.5/0.4	---	---	---	---	---	10
G657A2	0.36/0.22	0.5/0.4	---	---	---	---	---	7.5
OM3	---	---	3.0/1.0	3.5/1.5	≥1500/500	≥2000	≤300	30
OM4	---	---	3.0/1.0	3.5/1.5	≥3500/500	≥4700	≤550	30

Self-supporting Bow-type Fiber Optic Drop Cable

FAQ

I-Q1: Ngaba le ntambo ingasetyenziselwa kwiindawo ezinomoya ophezulu?

I-A1: Ewe, ucingo lwentsimbi kunye nokuqiniswa kwe-FRP kunika amandla okwaneleyo okumelana nomthwalo oqhelekileyo womoya ekuhanjisweni emoyeni.

I-Q2: Ngaba intambo ifanelekile kufakelo lwasedolophini nasemaphandleni?

A2: Ewe, uyilo lohlobo lwesaphetha kunye nolwakhiwo olukhaphukhaphu luyenza ikwazi ukuziqhelanisa needolophu ezixineneyo kunye neendawo ezisemaphandleni ezinabantu abambalwa.

I-Q3: Yintoni eyenza le ntambo yokuzimela?

I-A3: Ukudibaniswa kweeyunithi ze-fiber central, i-FRP ehambelanayo okanye amalungu anamandla esinyithi, kunye nokuqiniswa kocingo olulodwa lwensimbi luvumela ikhebula ukuba ligcine ukuxhatshazwa ngaphandle kwenkxaso eyongezelelweyo.

Kutheni ukhetha iCable yokuZixhasa yeFiber Optic Drop?

Le ntambo inika ibhalansi yamandla omatshini, ukulungelelaniswa kofakelo, kunye nokukhuselwa kwendalo. Ithenjwe ngokubanzi ngababoneleli bonxibelelwano kunye nothungelwano lwemizi-mveliso, ibonelela ngentsebenzo ethembekileyo yokusasazwa kwefayibha ngaphezulu ngelixa kusenziwa lula ukugcinwa kunye nokudibanisa. Uyilo lwayo olusebenzayo kunye ne-LSZH sheath iqinisekisa ukhuseleko kunye nokuthotyelwa kweemfuno zokufakelwa kwenethiwekhi yanamhlanje.
