1 * 2 1 * 8 1 * 16 plc splitter

Thumela uMbuzo

Ingcaciso yeMveliso

I-plc splitter yindawo yokuqhawula umbane Ingabanikali amanqaku e-compact, i-waveedngth ebanzi, ukuthembeka okuphezulu kunye namandla amahle afanayo. Ngokukodwa, ilungele inethiwekhi yenethiwekhi yokudibanisa izixhobo eziphambili kunye nezithintelo zokuphelisa, ukuze zibone ukwenziwa kokukhanya kokukhanya. Inokuthenjwa ayinakuthembeka kuphela i-1 × n, kodwa inokubonelela nge-plc splitter ilungele izihlandlo ezahlukeneyo kwizicelo zabathengi.

Iimbonakalo:

● Ukuphula okuphantsi kwe-pdl ephantsi

● Amandla afanayo ahluma

● Ukuthembeka okuphezulu

● Ukuzinza kakuhle kwendalo

● Ubungakanani be-compact kunye neephakeji ezahlukeneyo

● I-rohs iyahambelana

Isicelo:

● Icandelo likaThengisi

● Inkqubo yePon

Ftti

● Ukuhanjiswa kwevidiyo ye-Catv

Inkcazo yokusebenza:

I-1xn plc splitter

Into		Iyunithi	Iparameter
Ukusebenza kwe-wavelength		nm	1260 ~ 1650
Uvavanyo lwavelength		nm	1310/1550
Inombolo ye-Chanel		-	1x2	1x8	1x16
Ukufakwa kwelahleko	Max	db	≤3.8	≤10.4	≤13.5
Ukufana	Max	db	≤0.6	≤1.0	≤1.2
Ilahleko yokuxhomekeka kwendalo	Max	db	≤0.25	≤0.3	≤0.30
Buyisela ilahleko	Imiz	db	≥50
Ngqondo	Imiz	db	≥55
Uhlobo lweFiber			I-IT657 A1 fiber
Iqondo lobushushu		℃	-40 ~ +85
Iqondo lokugcina		℃	-40 ~ +85
